· Suitable for both colour matching and mixing of paints and pigmented bases and the blending of iquid-iguid, liquid-solid phase materials in other mixing industries. Colour matching is completed quicky by the action of the blending mechanism.
· The machine is robustly fabricated and is easily installed.
Product parameters
Model | Motor (kw) | Tank Volume (m³) | Speed (r/min) | Impeller (mm) | Impeller Quatity | Exernal Dimensions | ||
---|---|---|---|---|---|---|---|---|
D (mm) | H (mm) | H1 (mm) | ||||||
TC0.5 | 1.1 | 0.5 | 130 | 500 | 2 | 800 | 1100 | 860 |
TC1 | 2.2 | 1 | 130 | 500 | 2 | 1000 | 1400 | 860 |
TC2 | 4 | 2 | 88 | 800 | 2 | 1400 | 1600 | 1170 |
TC3 | 5.5 | 3 | 88 | 900 | 2 | 1500 | 1900 | 1290 |
TC4 | 7.5 | 4 | 88 | 950 | 2 | 1600 | 2200 | 1290 |
TC5 | 11 | 5 | 88 | 1200 | 2 | 1800 | 2300 | 1670 |
TC6 | 15 | 6 | 88 | 1300 | 2 | 1900 | 2300 | 1670 |
TC8 | 18.5 | 8 | 63 | 1200 | 3 | 2000 | 2800 | 1910 |
TC10 | 22 | 10 | 63 | 1250 | 3 | 2200 | 2800 | 1930 |
