· Specially designed for mixing chemical products with high viscosities.
· Low speed tri-foi mass moving mixing device ensures the maximum materialturn over. The strong high speed saw toothed shearing head created excelent disoersina condiions. The matellals continwally reaches the dispersing blade by the aclion of the tri-oll mixer and dissolving requirements are quicky achieved.
· The mechanios of high and low shear rates results in unilom dispersions through a wide range medium to high ciscosities.
· The unit is also available with vacuum facility.
· Suitable for viscous printing inks, adhesive agenta, putties, fillers an litho inks.
Product parameters
Model | Mixer Motor (kw) | Dispersing Motor (kw) | Mixer Speed (r/min) | Disperser Speed (r/min) | Lifting (mm) | Tank Volume (L) | Speed Controlled |
---|---|---|---|---|---|---|---|
SJ600 | 5.5 | 18.5 | 0~1450 | 2 | 1400 | 1650 | 1930 |
SJ900 | 5.5 | 22 | 0~1450 | 2 | 1600 | 1765 | 2000 |
SJ1200 | 7.5 | 30 | 0~1450 | 2 | 1800 | 2048 | 2200 |
