· Suitable for high speed-dissolution, dispersing and particulate wetting
· Utilised for premixing coatings, dyes, pigments, printing inks, paper coatings, adhesives and chemicals.
· Characterised with low air intake at the vortex with excellent mixing and dispersing aclion resulting in uniform particle
sizes.
· With variable speed availability the mixing and dispersing of the material can be achieved very quickly with the finest ofparticle sizes.
Product parameters
Model | Main Motor (kw) | Speed (r/min) | Disc Diameter (mm) | Lifting (mm) | Hydraulic Motor (kw) | Capacity (L) | Weight (kg) | External Dimensions | |||
---|---|---|---|---|---|---|---|---|---|---|---|
A (mm) | B (mm) | C (mm) | W (mm) | ||||||||
FL1.5 | 1.5 | 0-1450 | 150 | 550 | 0.55 | 50 | 120 | 1300 | 950 | 515 | 350 |
FL4 | 4 | 0-1450 | 200 | 800 | 0.55 | 200 | 400 | 1540 | 1300 | 600 | 550 |
FL11 | 11 | 0-1450 | 250 | 900 | 0.55 | 400-600 | 800 | 1750 | 1800 | 900 | 650 |
FL22/FX22 | 22 | 0-1450 | 350 | 1200 | 0.75 | 600-1200 | 1500 | 2200 | 2100 | 1100 | 900 |
FL37/FX37 | 37 | 0-1200 | 400 | 1200 | 1.1 | 1000-2000 | 1700 | 2200 | 2100 | 1100 | 900 |
FL45/FX45 | 45 | 0-1200 | 450 | 1600 | 2.2 | 1000-2500 | 2100 | 2800 | 2800 | 1300 | 1000 |
FL90/FX90 | 90 | 0-1000 | 600 | 1600 | 2.2 | 5000 | 2600 | 2800 | 3000 | 1600 | 1500 |
