This machine adopts a domestically innovative integrated block oil circuit design, controlled by an electromagnetic valve to manage the machine's working status. The response speed for pressing and releasing is fast, the pressure is uniform, and it is easy to control. Various fineness of the grinding material is achieved by adjusting the pressure; the oil circuit uses specially designed joints to ensure no leakage and facilitate maintenance and disassembly. The rollers are cast from specially formulated alloy materials, providing high strength and durability on the surface.
Product Parameters
Roller Diameter (mm) | Roller Working Length (mm) | Roller Speed (rpm) | Main Motor Power (kw) | Total Pressure of Hydraulic System (Mpa) | Hydraulic Pump Power (kw) | Machine Weight (kg) | Dimensions (mm) | ||
---|---|---|---|---|---|---|---|---|---|
Slow Roller | Middle Roller | Fast Roller | |||||||
260 | 650 | 49 | 140 | 400 | 18.5-22 | ≤6.17 | 1.5 | 2100 | 1670x1450x1290x900 |
400 | 800 | 31 | 122 | 400 | 30 | ≤6.17 | 1.5 | 4000 | 2040x1790x1390x1150 |
400 | 1000 | 31 | 122 | 400 | 37 | ≤6.17 | 1.5 | 4500 | 2240x1790x1390x1150 |
400 | 1300 | 31 | 122 | 400 | 55 | ≤6.17 | 1.5 | 5000 | 2540x1790x1390x1150 |
